INTEL
GIGABYTE H610M-K DDR4
DZD 18,900
View on seller's websitePrices and availability are updated daily. Please confirm on the seller's website before buying.
Description
- Supports Intel® Core™ 14th/ 13th /12th processors
- Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
- GbE LAN with Bandwidth Management
- NVMe PCIe 3.0 x4 M.2
- High Quality Audio Capacitors and Audio Noise Guard
- Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
- GIGABYTE APP Center, Simple and Easy Use
- Anti-Sulfur Resistors Design
| ITEM | SPECIFICATION |
|---|---|
| CPU Support | LGA1700 socket: 14th / 13th / 12th Gen Intel® Core™, Pentium® Gold, Celeron® |
| Chipset | Intel® H610 Express Chipset |
| Form Factor | Micro ATX Form Factor; 22.6cm x 18.5cm |
| Memory | 2 x DDR4 DIMM sockets (up to 64 GB) DDR4 3200/3000/2933/2666/2400/2133 MT/s |
| Memory Architecture | Dual channel |
| ECC Support | ECC Un-buffered DIMM 1Rx8/2Rx8 (non-ECC mode) Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 |
| XMP Support | Yes |
| Onboard Graphics | Integrated Intel® UHD Graphics 1 x HDMI 2.1 (4096x2160@60Hz) HDCP 2.3 |
| Audio | Realtek® Audio CODEC 2/4/5.1/7.1-channel HD Audio |
| LAN | Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
| Expansion Slots | 1 x PCIe 4.0 x16 (CPU) 1 x PCIe 3.0 x1 (Chipset) |
| Storage Interface | 1 x M.2 (PCIe 3.0 x4/x2, type 2280/2260) 2 x SATA 6Gb/s connectors |
| USB Ports (Rear) | 2 x USB 3.2 Gen 1 4 x USB 2.0/1.1 |
| USB Ports (Internal) | 1 x USB 3.2 Gen 1 header 1 x USB 2.0 header |
| Internal Connectors | 24-pin ATX main power 8-pin ATX 12V CPU & System fan headers TPM header Clear CMOS jumper |
| Back Panel I/O | 1 x HDMI 2 x USB 3.2 Gen 1 4 x USB 2.0 1 x RJ-45 3 x Audio jacks |
| H/W Monitoring | Voltage, temperature, fan speed, water cooling flow, fan fail warning |
| Fan Speed Control | Yes (dependent on cooler) |
| BIOS | 128 Mbit AMI UEFI BIOS |
| BIOS Features | Q-Flash, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | APP Center, @BIOS, EasyTune, Smart Backup, System Info Viewer |
| Bundled Software | Norton® Internet Security (OEM), LAN Bandwidth Management |
| OS Support | Windows 11 64-bit, Windows 10 64-bit |
