• Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series processors
• Supports DDR4 Memory, up to 4600(OC) MHz
• Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
• Core Boost: With premium layout and digital power design to support more cores and provide better performance.
• DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
• 2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability.
• Audio Boost: Reward your ears with studio grade sound quality
• Dragon Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface.

Specification

Socket	AMD Socket AM4
Chipset	AMD® A520 Chipset
Memory Channel	Dual
DIMM Slots	2
Max Memory (GB)	64
PCI-E x16	1
PCI-E Gen	Gen3
PCI-E x1	1
SATAIII	4
M.2 Slot	1
RAID	0/1/10
TPM (header)	1
USB 3.2 ports (Front)	2(Gen 1, Type A)
USB 3.2 ports (Rear)	4(Gen 1, Type A)
USB 2.0 ports (Front)	4
USB 2.0 ports (Rear)	2(Type A)
Serial ports(Front)	2(Type A)
Audio ports (Rear)	Realtek® ALC892/ALC897 Codecxt
DVI-D	1
HDMI	1
DirectX	12
CPU Support	Support for Windows® 10 64-bit
Form Factor	MATX
